Clear 4.0mm OD 2.0mm ID Medical Grade Silicone Tubing
High Transparent FDA Platinum Cured Silicone Tube
Silicone tube is extruded and molded by environmental non-toxic
silica raw materials through a special process. Product has good
performance at flexibility, abrasion and distortion and it can be
resistant to many kinds of solvents, oils, acids and diluted sodium
hydroxide. It can’t pollute the products covered by it, quite
suitable for medical, food and dairy industries.
Specification Of High Transparent FDA Platinum Cured Silicone Tube
| Material | 100% imported silicone |
| Large Size Rank | OD1.0mm ~60mm; ID 0.3mm~ 59mm |
| Color | blue, white, red, green, yellow,transparent |
| Hardness | 30~80 Shore A |
| Temperature range | From -40 centigrades to 280 centigrades |
| Certification | FDA, LFGB, USP,SGS |
| Package | Bulk or 1 roll of foam strip in a pp bag,usually 20kgs per carton,
or less.or customized.( Packing 6m/pcs, 10m/pcs, 24m/pcs, 150m/pcs) |
| Feature | 1. Made of non-toxic PVC or medical-grade silicone,clear and soft. 2. Radio opaque line through the length for x-ray visualization. 3. Easily cut to your desired length 4. High Temperature Resistance: -50~280 centigrade |
| Application | General usage for medical equipments, home appliances, military
equipment, motors,industrial electrical, etc. |
| Market | Europe, USA, the Middle East, the Costa Rica, Peru, Russia,Egypt,
Australia, etc. |
Application Of Medical grade flexible silicone hose elastic
silicone rubber tube
High-temperature resistant food grade silicone tube application;
Food-grade transparent silicone tube is widely used in medical
equipment, electronic appliances, chemical experiments,
bio-pharmaceuticals, food processing, fitness equipment, ships And
other fields.
casing and Instrument; connecting pipe, tube
Automotive, Industrial, Medical, Agricultural
Features Of Silicone Tubing
1. Strength (high strength-to-weight ratio)
2. Chemical inertness of this PTFE teflon oil seal is good
3. Biocompatibility
4. High thermal resistance
5. High chemical resistance in harsh environments
6. Low flammability
7. Low coefficient of friction
8. Low water adsorption
9. Good weathering properties
| Model | Internal diameter
mm | Outside diameters
mm | Tolerance
mm(+/-) | hardness A |
| JE-001 | 1.0 | 2.0 | 0.05 | 30-80 |
| JE-002 | 2.0 | 4.0 | 0.05 | 30-80 |
| JE-003 | 3.0 | 5.0 | 0.05 | 30-80 |
| JE-004 | 4.0 | 6.0 | 0.05 | 30-80 |
| JE-005 | 4.0 | 8.0 | 0.05 | 30-80 |
| JE-006 | 5.0 | 7.0 | 0.05 | 30-80 |
| JE-007 | 5.0 | 10.0 | 0.05 | 30-80 |
| JE-008 | 6.0 | 9.0 | 0.05 | 30-80 |
| JE-009 | 6.0 | 10.0 | 0.05 | 30-80 |
| JE-010 | 8.0 | 10.0 | 0.1 | 30-80 |
| JE-011 | 8.0 | 12.0 | 0.1 | 30-80 |
| JE-012 | 9.0 | 12.0 | 0.1 | 30-80 |
| JE-013 | 10.0 | 12.0 | 0.1 | 30-80 |
| JE-014 | 10.0 | 14.0 | 0.1 | 30-80 |
| JE-015 | 12.0 | 16.0 | 0.1 | 30-80 |
| JE-016 | 12.0 | 18.0 | 0.1 | 30-80 |
| JE-017 | 14.0 | 20.0 | 0.1 | 30-80 |
| JE-018 | 14.0 | 24.0 | 0.1 | 30-80 |
| JE-019 | 16.0 | 20.0 | 0.1 | 30-80 |
| JE-020 | 20.0 | 26.0 | 0.1 | 30-80 |
Our Services:
1. Top grade quality, and strong competitive price.
2. Food -Grade, Science & Green Product.
3. Logo can be Printed as Customers’ Drawings and Samples.
4. OEM orders are welcome.
5. We own our technical equipment and designer, can make all kinds
of silicone products according to customer's request.
6. Fast speed in making new models for customizing items.
FAQ:
Q: Is Customized silicone tube available?
A: Yes. Please offer your required specifications and drawing.
Q: What format of the file do you need if I want my own desig n?
A: JPG, AI, CDR or PDF, SETP etc. We have professional designers
and we can draw artwork for you.
Q: Are you factory or trading company?
A: Manufacturer with factory.
Q: What kind of silicone products do you produce?
A: Various levels of silicone extrusion products, custom silicone
sealing ring, various shapes silicone strip, etc.
Q: Is free sample available?
A: Yes! One meter free sample. But you need to pay the shipping
cost.
Q: What’s your MOQ?
A: Any quantity is Ok. The price depend on your quantity, we will
quote for your accordingly.
Q: What’s your delivery time?
A: 1) Generally the samples will be sent immediately by the air
express if the goods are in stock.
2) Normally with 7-10 days after received payment. Please confirm
with us before order.
